Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory
Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory
Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory
Contact Now

Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : 200pcs/box, 10boxes/carton; For standard size card or customized boxes or cartons as required. Delivery Time : 7 week days
Payment Terms : T/T Supply Ability : 100,000 pcs per week
Place of Origin: China Brand Name: Wisecard Technology
Certification: ISO14443,7816 Model Number: CIU9872B

Detail Information
CPU: 32 Bit Main Frequency: 72MHZ
Timer: 2 * 16/32bit Timer EEPROM: 152KB
Interface 7816: Comply With ISO/IEC 7816 T=0/1 Standard; Supports Up To 446400bps Interface 14443: Comply With ISO/IEC 14443 TYPE A Standard
Interface I2C: Supports Master-slave Mode, Support 400KHZ Interface GPIO: 2
Highlight:

Cryptographic Algorithms emv quick chip

,

EMV quick chip 72MHZ

Product Description

72MHZ Main Frequency CPU 152KB Memory EMV Chip

Product Description:

CIU9872B_01 Plus chip uses 32-bit secure CPU core and EEPROM memory, supports hardware cryptographic algorithms (DES/AES/ECC/RSA/SHA-n, SM1/SM2/SM3/SM4), supports multiple interfaces: 7816/14443/ I2C / GPIO, for financial applications. EMV originally stood for Europay, Mastercard, and Visa, the three companies that created the standard. The standard is now managed by EMVCo, a consortium with control split equally among Visa, Mastercard, JCB, American Express, China UnionPay, and Discover. EMVCo also refers to "Associates," companies able to provide input and receive feedback on detailed technical and operational issues connected to the EMV specifications and related processes.



Specification:

CPU Security Features
CPU 32 bit Security algorithm supports DES/3DES/AES
Main frequency 72MHZ supports SM1/SM4/SM3
Timer 2 * 16/32bit Timer supports RSA/ECC/SM2
　 　 Random
number		 Supports true random number, in line
with AIS31-P2 standard
Memory Memory Supports memory security protection
mechanism
EEPROM 152KB Sensor Supports multiple safety sensor
detection
Erasing and writing
≥ 500,000 times		 Active shield support
Data storage time
≥ 25 years		 Unique serial
number		 The unique serial number of the chip
cannot be changed
　 　 Self-check
function		 Support self-check safety reset
　 　 　 　
Interfaces 　 Package Form
7816 Comply with ISO/IEC 7816
T=0/1 standard		 Module
Package		 Dual interface
Supports up to 446400bps 6PIN Silver/Gold
14443 Comply with ISO/IEC 14443
TYPE A standard		 Applications
Supports up to 848Kbit/s EMV standard payment
I2C Supports master-slave mode,
support 400KHZ		 1)Supports VISA(VSDC2.8.1g1)+ Mastercard
(MChip Advance 1.2.3)Dual APP
GPIO 2
Electrical Characteristics 　
Operating
Voltage		 1.6V～5.5V 2)Supports Mastercard(MChip Advance 1.2.3)
Operating
temperature		 -25℃~85℃
ESD 7816interface 6KV(HBM)
14443interface 4KV(HBM) 　



Service:

1. QC: Every single card will be carefully checked by machine or manual work before dispatched.

2. Accept personalized customization.

3. Strict quantity control on processing.

4. On time delivery.

5. Quality assurance: 1year warranty after delivery.

6. Quick response: Your inquiry will be replied in 24 hours.



FAQ:

Q: What about the Warranty?
A: We provide one year warranty for main device as well as 24 hours online service to help you out.



Q: Are you manufacturer?
A: Yes.Our company headquarters is located in Nanjing of China, factory in shenzhen.



Q: Can you provide application software for the hardware?
A: We provide free SDK and User manual of all API to support your development or programming.



Q: Does the device have the language default as English?
A: Of course, our device supports multi-language such as English, Spanish, Portuguese ,French, German, Polish and so on.



Q: Can your device install the Android Apps that our customers provide?
A: No problem. Just send us your Apps and then our Engineers can do that for you.






Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory 0Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory 1Cryptographic Algorithms EMV Quick Chip 72MHZ Main Frequency CPU 152KB Memory 2
